The STS-126 patch represents Space Shuttle Endeavour on its mission to help complete the assembly of the International Space Station. Image: NASA
For years, STS-126 has been planned as the mission that will give the International Space Station the ability to support twice the crew currently living there. But since the most recent inspection of the station’s solar alpha rotary joint, it’s also become the mission that will ensure the station can generate the power those extra crew members will require.
All together – and with a few other tasks thrown in for good measure – there will be a busy four days of spacewalking outside the station. But that doesn’t mean a break for those left inside.
“If the outside work doesn’t get you excited,” said Ginger Kerrick, lead station flight director for the mission, “the inside work will.”
The power generated by the two SARJs will be put to good use next year when the station increases to a crew of six, rather than the current three. STS-126’s main purpose is to get the station ready for the expansion, and space shuttle Endeavour is bringing with it a multi-purpose logistics module loaded with about 32,000 pounds of equipment with which to do so.
“It’s the most jam-packed logistics module we have ever carried up there,” STS-126 Commander Chris Ferguson said. “We’re taking a three-bedroom, one-bathroom house and turning it into a five-bedroom, two-bathroom house with a gym.”
The solar alpha rotary joints are two 10-foot-wide, wagon-wheel-shaped joints on the station’s truss that allow the electricity-generating solar arrays to rotate so that they’re always getting as much sun as possible. Flight controllers on the ground noticed a year ago that it was taking more power than normal to rotate the SARJ on the station’s starboard – or right – side, and it was vibrating more than it should.
The STS-126 crew members take a break during a training session for a portrait with their crew logo in the Space Vehicle Mock-up Facility at NASA's Johnson Space Center. Image: NASA
Over several spacewalks to inspect the joint, engineers narrowed the more than 100 possible causes down to one: insufficient lubrication. Without enough lubrication, the trundle bearing assemblies that hold the two halves of the joint together, and allow one side to rotate while the other stays still, were pressing too hard against one side of the joint. This added pressure damaged the steel of the joint’s “wheel,” which the bearings roll against, and left metal filings that could cause more damage.
So spacewalkers Heidemarie Stefanyshyn-Piper, Steve Bowen and Shane Kimbrough will spend the majority of the four spacewalks planned during the 15-day mission fixing that. They’ll start by cleaning the metal shavings off of the surface, then lubricate it and replace the trundle bearing assemblies – all of which is more complicated than you might expect.
The astronauts will have to go out and remove the thermal covers that protect the SARJ – no more than four at a time, though, due to thermal concerns – removing the trundle bearing assemblies – no more than two at a time – cleaning the surface, lubricating it, installing new trundle bearing assemblies and reinstalling the thermal covers.
“You might think of putting a crew member out there with a wipe and just rotating the SARJ underneath them, but that of course presents safety hazards,” Kerrick said.
Following the first spacewalk, the spacewalkers will go back inside and the SARJ will be rotated so that the newly clean sections are under the two massive drive lock assemblies that cause the SARJ to rotate, leaving the rest of the surface accessible for cleaning on the second and third spacewalks.
Astronauts Sandra H. Magnus (foreground), Expedition 18 flight engineer; Robert S. (Shane) Kimbrough and Heidemarie M. Stefanyshyn-Piper, both STS-126 mission specialists, give a "thumbs-up" signal during a training session in one of the full-scale trainers in the Space Vehicle Mockup Facility at Johnson Space Center. Image: NASA
“To a certain degree, it’s repetitive,” Ferguson said. “You remove a cover, remove a trundle bearing, clean, lubricate. Replace the trundle bearing, replace the cover. But the thing is, you want to make sure you get the technique right. That’s what takes the three spacewalks.”
But the experience of those three spacewalks should stand them in good stead for the fourth spacewalk of the mission, when they compress the lubrication of the port SARJ into one spacewalk.
The port SARJ hasn’t experienced any problems or shown any of the damage the starboard SARJ has. But to be on the safe side, the spacewalkers will go ahead and lubricate its surface to keep the problem from developing in the future. Hopefully this will save the time of having to go and clean it and replace its trundle bearing assemblies later on.
“We’re working on the starboard SARJ; we’re working on the port SARJ. If there’s a SARJ up there, we’re working on it,” Kerrick said.
Back inside, the crew – which, in addition to Ferguson, Piper, Bowen and Kimbrough, includes Pilot Eric Boe, Mission Specialist Donald Pettit and the station’s next flight engineer, Sandra Magnus – will spend a lot of time unpacking new crew quarters, a new toilet, a new kitchen, a new refrigerator and new exercise equipment, not to mention the science experiments.
“We’re going to use up a lot of the new space that we’ve brought up on the past few missions, with Node 2 and Columbus and the Kibo module,” lead shuttle flight director Mike Sarafin said. “The six-person crew is an important step toward utilizing the space station to its full capability.”
But in addition to fully utilizing the space station, the equipment brought up will allow the space station to start depending less on the space shuttle. A new regenerative environmental control and life support system will give the station the ability to recycle urine and the condensation that the crew breathes into the air into pure water that can be used for drinking or to cool the station’s systems.
Astronaut Steve Bowen, STS-126 mission specialist, participates in an Extravehicular Mobility Unit (EMU) spacesuit fit check in the Space Station Airlock Test Article (SSATA) in the Crew Systems Laboratory at NASA's Johnson Space Center. Image: NASA
That will be important when the shuttle fleet is retired in 2010, and its water deliveries dry up.
“Up until this point, the majority of the station’s drinking water was coming up from the shuttle or the Russian’s Progress vehicle,” Sarafin said. “This sets us up for long-term sustainability of the station without the shuttle.”
Nobody will be drinking the water generated by the system just yet – an onboard purity monitor needs to be checked out and multiple water samples must be analyzed by scientists on the ground first. To get that water sample home as quickly as possible, Endeavour’s crew will take a shot at getting the system hooked up before they leave. If they’re able to do so, it will be no small feat.
“We’ll be transitioning to true utilization and setting up for six-person crew at that 10-year bench mark,” Sarafin said. “It’s been a tremendous international effort to get to this point, and I can’t think of a better way to celebrate it.”
It would also be a good way to mark the 10th birthday of the International Space Station on Nov. 20 – 10 years after the first station module was launched into space and construction began.
“The regenerative life support system checkout is also highly choreographed,” Kerrick said. “The crew has to set up the racks and install some critical hardware. Then the ground has to perform some initial checkouts. After that there are a series of crew and ground steps that must occur in a particular sequence - all leading up to a sample that will be generated around flight day 11. This was not part of our original timeline, but something that has become a very important mission priority so we can be prepared to provide a ‘go’ for six-person crew operations late next spring.”
