125- NASA STS-119 Official Mission Lapel Pin
in stock

STS-119 Official Mission Lapel Pin - 125th Space Shuttle Flight

STS-119: A Final Station Power Up

JSC2008-E-052124 -- STS-119 crew

Attired in training versions of their shuttle launch and entry suits, the STS-119 crew members await the start of a training session in the Space Vehicle Mockup Facility at Johnson Space Center, Houston. Image: NASA

If the International Space Station crew wants to invite three more people to join them in living full time in space, the space shuttle Discovery crew says more power to 'em – literally.

The STS-119 mission will deliver to the station the final set of solar arrays needed to complete the station's complement of electricity-generating solar panels, and through them support the station's expanded crew of six in 2009.

"More crew means that we'll have to run more life support equipment, more crew support equipment – toilet facilities, water processing equipment and all of that stuff," said Kwatsi Alibaruho, the lead space station flight director for the mission. "We'll have to run more of all of that, so we need additional power."

And that's not even counting the science.

Over the past year, one new connecting node – Harmony – and two new international partner laboratories – the European Columbus and the Japanese Kibo – have been added to the space station, expanding its capacity for science experiments. And one of the reasons the crew is being expanded is to have more hands aboard performing those experiments. The additional electricity provided by the new solar arrays will help power those experiments.

The set of solar arrays that the STS-119 crew will be bringing up includes two solar array wings, each of which has two 115-foot-long arrays, for a total wing span of 240 feet, including the equipment that connects the two halves and allows them to twist as they track the sun. Altogether, the four sets of arrays can generate 84 to 120 kilowatts of electricity – enough to provide power for more than 40 average homes. Since the three existing arrays can handle the majority of the station's day-to-day operational and life support needs, the newest solar array will double the amount of power available for scientific research.

"We're able to do a lot of things in our current configuration, and we're not too power limited," Alibaruho said. "But we still have some other things to get on orbit. We don't have the Columbus module and the Kibo module completely full of experiments, the way we expect to have it in coming years. So we need the additional power capability to be able to expand the science capability."

Adding the additional power may prove a bit tricky, however. This will be the fourth truss segment sporting solar array wings to be installed on the station, but only the second that's quite this far out on the station's truss. The segment is called the S6 truss – "S" for starboard, the right side of the station, and "6" for its place at the very end of the starboard truss.

JSC2008-E-137430 -- STS-119 Mission Specialist Richard Arnold

STS-119 Mission Specialist Richard Arnold participates in an Extravehicular Mobility Unit spacesuit fit check in the Space Station Airlock Test Article in the Crew Systems Laboratory at Johnson Space Center. Image: NASA

To install it, the station's robotic arm must extend its reach just about as far as it will go, leaving it with very little room to maneuver. The same was true of its mirror image on the port side of the station – the P6 truss segment – so the crew expects to be able to pull it off without a hitch. But that doesn't mean it will be easy.

"We've done it before, but we haven't done it with these exact same people," Discovery's commander, Lee Archambault, said. "But there are some very good lessons learned out there, and we'll certainly capitalize on those."

With Archambault, Discovery's crew includes Pilot Tony Antonelli and Mission Specialists Richard Arnold, Joseph Acaba, John Phillips, Steve Swanson and Koichi Wakata of the Japan Aerospace Exploration Agency. Wakata will stay aboard the station after Discovery docks -- becoming the first JAXA station crew member -- while astronaut Sandy Magnus, who arrived at the station on mission STS-126, will return home.

More lessons learned for Discovery's mission will come, in particular, from previous experience unfolding the solar arrays. When the first set of the station's solar arrays was unfolded during the STS-97 mission, the crew ran into a problem called "stiction" – the plastics and polymers that coat the panels of the solar arrays stuck together. Then later, when those same solar arrays were folded up, moved and redeployed, the wires that guide the panels got snagged, causing one of the arrays to tear.

These arrays aren't likely to ever need to be folded up and moved to a new location, and by the time the second set of arrays was ready for installation, engineers had come up with a way around the stiction problem. So neither of those issues is expected to crop up this time around. Still, lead shuttle flight director Paul Dye said that doesn't mean you can expect it to go smoothly.

"It's always the thing that you think you have down, that's routine, that comes back and bites you," Dye said. "It'll either be routine or it will be heart stopping, like always."

JSC2008-E-140065 -- STS-119 Commander Lee Archambault Pilot Tony Antonelli

STS-119 Commander Lee Archambault (left) and Pilot Tony Antonelli stand near a NASA DC-9 aircraft prior to a Heavy Aircraft Training session at Ellington Field near Johnson Space Center. Image: NASA
